Desktop Intermediate-Frequency Inverse DC Spot Welding Machine For

Basic Information
Place of Origin: CHINA
Brand Name: PDKJ
Certification: CE ISO SGS
Model Number: DB-80T
Minimum Order Quantity: 1 unit
Price: 9200 USD
Packaging Details: Wooden Case
Delivery Time: 5-25 days
Supply Ability: 100 set per month
Detail Information
Welding Style: Resistance Welding Usage: Spot Welding
Key Selling Points: Quick,Seamless Applicable Industries: Building Material; Machinery Repair; Sheet Metal
After-sales Service: Field Installation; Site Commissioning And Training Welding Thickness: 1.0+1.0mm

Product Description

Desktop Intermediate-frequency Inverse DC Spot Welding Machine , Spot Welding Machine projection welding machine with CE/CCC/ISO certificate

TDesktop medium frequency inverter spot welder is suitable for welding fine workpieces such as electrical switches, purple copper wire joints, terminal wires, silver contacts, chip inductors, coils, fuses and hardware. It is widely used in the welding of precision components such as electronics, electrical appliances, medical devices, instruments and meters.



parameter DB-80T
Rated capacity 80KVA
Input power three φ 380V
short-circuit current 22000A
Load duration 20%
control mode Primary / secondary constant current
Inverter frequency 1000HZ
Arm extension size 120 mm x115mm
Cooling water flow 4L/min
weight 150kg
Overall dimension (mm) 800*670*765mm

Desktop Intermediate-Frequency Inverse DC Spot Welding Machine For 0

01.Adjustable vertical pressure mechanism, the guide part adopts linear guide rail, with high follow-up.

02.Desktop structure, beautiful and generous, space saving and flexible configuration.

03.Safe and high-performance pneumatic system, the pressurization speed can be adjusted at will.

04.The water-saving circulating water cooling system is equipped with fast water cooling connector to facilitate the replacement of water cooling, electrode or fixture.

05.The output current is DC, the current is smooth, the inductive reactance is zero, the working frequency is 1000Hz, and the time control accuracy is 1ms.

06.High quality and high efficiency welding capacity, power factor up to 98%, three-phase input load balance.

Especially suitable for aluminum, copper, galvanized sheet, carbon steel, nickel, tungsten and other metal materials and high temperature enameled wire, flexible connection, inductance coil welding. It is widely used in the welding of metal products in the fields of automobile and auto parts manufacturing, new energy power battery, photoelectric communication, electric light source, compressor, hardware, furniture, kitchenware, etc. The product has passed the patent certification of China Intellectual Property Office, China CCC certification and export CE certification

Desktop Intermediate-Frequency Inverse DC Spot Welding Machine For 1
1. When can you arrange shipment?
We usually arrange shipment within 15 days after getting deposit, but customized machines should be more than 25 days. We always ship by air and sea in the mean time.
2. Do you inspect the finished products?
Yes, Each step of production products will be came out inspection by QC department before shipping.
3. What’ your warranty and after-sales?
We offer 1 year warranty, various forms of online instruction and the spare parts. Professional engineers will solve problem, if necessary.
4. How about your transport packing? Is it possible to damage the machine during the transportation?
We have rich experience on international transportation. All the packing are extra thickness carton filling with protective PE foam and waterproof membrane. No damage happened during transportation until now.
